The key thing is that you must use a 'machine' id of 'pc-1.3' or it will say your hardware is not supported.

Voice Technology Support
Cisco Cucm 8.6.2 Will
Cisco Cucm 8.6 End Of Life

Additionally you MUST use a virtio disk or you will get a ks_pre.sh error as soon as the install starts (a look at logs will show it can't find a disk). This is funny because even though the OS finds the disk and an fdisk -l shows it, it looks like the script looks for a /dev/vda device (virtio) and nothing else, so if you didn't use Virtio as your disk and you have a /dev/sda it won't work. Or follow the step below to change the search pattern of vd to sd

In Promxox you will have to edit your config file like this:

bootdisk: sata0 cores: 12 ide2: local:iso/Bootable_UCSInstall_UCOS_12.iso,media=cdrom,size=3523684K machine: pc-1.3 memory: 8096 name: ciscouc net0: virtio=DE:C3:A0:F8:50:11,bridge=vmbr0 numa: 0 ostype: l26 scsihw: virtio-scsi-pci smbios1: uuid=99bf1ee3-b527-4ea2-bf68-179bee9699b1 sockets: 1 unused0: thin:vm-124-disk-1 virtio0: thin:vm-124-disk-2,size=90G

Raw QEMU-KVM execution:

Cisco Collaboration Training - 100% Focus on UC Collaborations. Jul 26, 2014 The Cisco Unified Communications Manager Version 8.6 has been retired and is no longer supported. End-of-Sale Date: 2014-07-26. End-of-Support Date: 2017-07-31. Cisco's End-of-Life Policy. You can view a listing of available Cisco Unified Communications Manager (CallManager) offerings that best meet your specific needs. If you want support. About Press Copyright Contact us Creators Advertise Developers Terms Privacy Policy & Safety How YouTube works Test new features Press Copyright Contact us Creators.

qemu-system-x86_64 -boot dc -smp 4 -machine pc-1.3 -vnc :1 -m 8096 -drive file=cucum86.img,if=virtio -cdrom Bootable_UCSInstall_UCOS_12.iso

The Cisco Unified Communications Manager Version 8.6 has been retired and is no longer supported. End-of-Sale Date: 2014-07-26. End-of-Support Date: 2017-07-31. Cisco's End-of-Life Policy. You can view a listing of available Cisco Unified Communications Manager (CallManager) offerings that best meet your specific needs. If you want support. Through this video, I'll show you how to upgrade a CUCM/CUPS 8.6 to CUCM/IM&P 11.0This video is no replacement for reading the documentation on the upgrade.

The following assumes you are mounting your CUCM iso into 'cucmmount'

#we make the following directories (cucmmount is where we mount the iso and cucmeditiso is where we copy the files to so we can modify and recreate the .iso)

mkdir cucmmount

mount -o loop yourcucm.iso cucmmount

#we copy our iso files to cucmeditiso

cp -a cucmmount cucmeditiso

cd cucmeditiso cd Cisco/hssi/server_implementation rm -rf OpenStack VMWARE cd KVM rm -rf HAL RHEV cd ./././.

vi Cisco/hssi/shared/bin/hssi_api.sh
#change
case '$isFound' in '0') echo '$($impl HWModel): passed detection validation' >&2 append_inDataFile_forKey_value $hssi_api_state_file 'hardware_implementation_paths' $impl hw_model='$($impl HWModel)' ((validated_count++)) ;;
#to
echo 'HSSI_API $impl returned $isFound and errors=$validation_errors ' >&2 case '$isFound' in '0') echo '$($impl HWModel): passed detection validation' >&2 append_inDataFile_forKey_value $hssi_api_state_file 'hardware_implementation_paths' $impl hw_model='$($impl HWModel)' ((validated_count++)) ;; '2') echo '$($impl HWModel): passed detection validation' >&2 append_inDataFile_forKey_value $hssi_api_state_file 'hardware_implementation_paths' $impl hw_model='$($impl HWModel)' ((validated_count++)) ;;
vi Cisco/base_scripts/ihardware.sh
#change
function hasHwSnmpMonitoring() { local method='hasHwSnmpMonitoring' _forwardToSAM $method $@ }
#to
function hasHwSnmpMonitoring() { return 1 }
mv Cisco/hssi/server_implementation/KVM/QEMU/shared/bin/api_implementation.sh.proposed Cisco/hssi/server_implementation/KVM/QEMU/shared/bin/api_implementation.sh vi Cisco/hssi/server_implementation/KVM/QEMU/shared/bin/api_implementation.sh
#find this
return $rc
}

#add this below the }
function postBootHardwareSetup() { local rc=$HSSI_TRUE (super postBootHardwareSetup $*) local src=$? # Abort if there is a critical failure if [ $src -eq 1 ]; then return $src fi rm -f /etc/udev/rules.d/70-persistent-net.rules 2> /dev/null # # remove hwaddr field from config in case mac address changed. # sed -i 's/^HWADDR.*//' /etc/sysconfig/network-scripts/ifcfg-eth* 2> /dev/null sed -i 's/^NM_CON.*/NM_CONTROLLED='no'/' /etc/sysconfig/network-scripts/ifcfg-eth* 2> /dev/null sed -i 's/^ONBOOT.*/ONBOOT='yes'/' /etc/sysconfig/network-scripts/ifcfg-eth* 2> /dev/null return $rc }

#follow this step if you want it to work with a NON virtio disk (eg. Virtualbox)

vi ./Cisco/hssi/server_implementation/KVM/QEMU/shared/bin/api_implementation.sh

################################### ### SERVER SPECIFIC OVERRIDES BELOW ################################### VDX_PATTERN='vd' KVM_SDX_PATTERN='sd' DX_INDEX=(a b c d e)

change VDX_PATTERN='vd' to VDX_PATTERN='sd'

################################### ### SERVER SPECIFIC OVERRIDES BELOW ################################### VDX_PATTERN='sd' KVM_SDX_PATTERN='sd' DX_INDEX=(a b c d e)

Now we generate our new .iso

genisoimage -o /tmp/KVMenabled-by-realtechtalk.com.iso -b isolinux/isolinux.bin -c isolinux/boot.cat -no-emul-boot -boot-load-size 4 -boot-info-table -J -R -iso-level 4 .

Errors:

ks_pre.sh error

Normally caused by not having your VDX pattern changed as above.

The Cisco Unified Communications disc was not found in any of your CDROM drives. Please insert the Cisco Unified Communications disc and press OK to retry.

Caused by lack of presence of the .discinfo text file from the root of cucmmount not being copied to your new iso root at cucmeditiso.

cp -a cucmmount/.discinfo cucmeditiso/

How To Modify the ISO to enable KVM

Tested on UCS 8.6 and 12

mkdir mountcucm mount -o loop Bootable_UCSInstall_UCOS_UNRST_8.6.2.10000-14.sgn.iso mountcucm/

#we need to copy the contents because we cannot directly edit a mounted (read-only) iso

cp -a mountcucm cucmedit

cd cucmedit

# we are enabling the KVM/QEMU by changing the api_implementation.sh.proposed to .sh

mv Cisco/hssi/server_implementation/KVM/QEMU/shared/bin/api_implementation.sh.proposed Cisco/hssi/server_implementation/KVM/QEMU/shared/bin/api_implementation.sh

#follow this step if you want it to work with a NON virtio disk (eg. in Virtualbox)

vi ./Cisco/hssi/server_implementation/KVM/QEMU/shared/bin/api_implementation.sh ################################### ### SERVER SPECIFIC OVERRIDES BELOW ################################### VDX_PATTERN='vd' KVM_SDX_PATTERN='sd' DX_INDEX=(a b c d e)

change VDX_PATTERN='vd' to VDX_PATTERN='sd'

################################### ### SERVER SPECIFIC OVERRIDES BELOW ################################### VDX_PATTERN='sd' KVM_SDX_PATTERN='sd' DX_INDEX=(a b c d e)

vi Cisco/base_scripts/ihardware.sh

#change this function hasHwSnmpMonitoring() { local method='hasHwSnmpMonitoring' _forwardToSAM $method $@ } #to function hasHwSnmpMonitoring() { return 1 }

cd Cisco/hssi/server_implementation

#delete everything other than KVM

total 40K drwxrwxr-x 8 900711 floppy 4.0K Aug 22 2011 . drwxrwxr-x 5 900711 floppy 4.0K Aug 22 2011 . drwxrwxr-x 5 900711 floppy 4.0K Aug 22 2011 HP drwxrwxr-x 6 900711 floppy 4.0K Aug 22 2011 IBM drwxrwxr-x 5 900711 floppy 4.0K Aug 22 2011 KVM -r--r--r-- 1 900711 floppy 92 Dec 13 2008 README.TXT drwxrwxr-x 4 900711 floppy 4.0K Aug 22 2011 shared -r--r--r-- 1 900711 floppy 1.5K Aug 22 2011 TRANS.TBL drwxrwxr-x 4 900711 floppy 4.0K Aug 22 2011 VMWARE drwxrwxr-x 4 900711 floppy 4.0K Aug 22 2011 VOLARIS

Voice Technology Support

#:/var/lib/vz/template/iso/cucm8.6kvm/Cisco/hssi/server_implementation# rm -rf HP/ IBM/ VMWARE/ VOLARIS/

#you may need to do this:

#fix this file vi Cisco/hssi/server_implementation/KVM/shared/bin/KVM.data #change expected_manufacturer=QEMU|Bochs #to expected_manufacturer=QEMU|Bochs|Seabios

#use mkisofs or genisoimage Vac anti cheat free download.

genisoimage -o /var/lib/vz/template/iso/Bootable_UCSInstall_UCOS_UNRST_8.6.2.10000-14.sgn-KVMenabled-by-realtechtalk.com.iso -b isolinux/isolinux.bin -c isolinux/boot.cat -no-emul-boot -boot-load-size 4 -boot-info-table -J -R -iso-level 4 .
